FT-160H

Faceplate Tailstock
FT-160H Faceplate Tailstock
FT-160H Faceplate Tailstock
FT-160H Faceplate Tailstock
FT-160H Faceplate Tailstock
FT-160H
  • Pneumatic Clamping: adopt complete disc-clamping system to enhance clamping force and to ensure continuous heavy-duty cutting
  • Hydraulic Clamping: adopt complete encircle hydraulic clamping system.
  • Able to be matched with TD, CV3,NC3 series.
  • If tailstock match with NC3, CV3 series, please select have delay valve(D)one.
Clamp Method Hydraulic 35kg/cm2
Faceplate Dimension Ø255mm
Spindle Through Hole Diameter Ø55mm
Centre Height 160mm
Clamp Force 50kgf-m
Net Weight (Without motor) 70kg
